MIDLAND SPD-8 DOUBLE-SIDED SELF-PROPELLED ROAD WIDENER
Road Wideners
The SPD-8 is a well-balanced and versatile road widener equipped with front-wheel drive, capable of efficiently conveying and placing aggregate and asphalt mixes up to 8 ft. from the edge of most pavements. Its modular curved spreader blade easily adapts to match various job spread widths, ensuring flexibility in operations.
The SPD-8 offers maximum versatility with its dual-sided discharge as a standard feature. With a 3 cu. yd. receiving hopper, 18 in. wide chain-driven conveyor, and 18 in. high spreader blade, it can convey and place up to 450 tons per hour, effectively saving time and money on any shoulder project. The SPD-8 is designed to tackle any job with ease. Witness the capabilities of the SPD-8 on your next shoulder or berm project.
Engine:
Model 4045D John Deere Diesel
74hp (55kw) tier 4/EU Stage V
Hydrostatic Traction Drive Two speed Transmission:
- Travel Speed 0- 8mph (13km/hr)
- Working Speed 0-150ft/min.(46m/min)
Front Wheel Steering / Drive
SAHR -Emergency/Parking Brake both F&R
FRONT 425/65R22.5, REAR 11R22.5 Tires
Strike off Blade:
1 -8ft (2.44m) Strike off width
Standard left &right hand blades, 18in (46cm )tall
Modular sections, 1ft (30cm) &2ft (60cm)
Optional Hydraulic Extension 2 - 4ft (61 - 1.22m)
Hydraulic Grade Control: 12in (30.5cm) above and below Grade
Hydraulic Slope control +/- 16%
PushRollers:
Extendable to 14in (35cm)
Oscillating, Self cleaning, Optional Hyd. Control
Conveyor:
Left or Right hand Discharge
Variable Speed Hydraulic Drive to 450 tph (409mt)
Two high torque Hydraulic motors.
Positive Chain drive, 18in (46cm) wide
Heat and oil resistant Material Belt.
Dimensions:
Weight: SPD-8 =19,260lbs (8,736kgs)
Transport Width: 11ft 11in (3.65m)
Length: 19ft (5.8 m)
Height: 8ft 3in (2.5m)
SP-8 =18,500lbs (8,692kgs)
Wheel Base: 110in (279cm)
Turning Radius: 15ft (4.57m)
