MANITOU TJ 65+ Telescopic Diesel
Have one to sell?
ConditionNew
New
Optimize your "height" handling work with our Manitou telescopic mobile elevating work platforms! The TJ 65+ telesocpic boom is designed to accommodate three operators, providing a platform capacity up to 899 lb. Along with this extra capacity, this model is also built with all the necessary features to facilitate your operations in high areas with difficult access: continuous 360 rotation, 3 driving modes (2/4 wheel or crab), durable chassis built for all-terrain, perforated platform floor, and transmission bridges. Take advantage of the exceptional performance of our MEWP line-up to improve your productivity and security of your crew on the jobsite.
Capacities
Working height 71 ft 4 in
Floor height (access) 1 ft 3 in
Platform height 64 ft 9 in
Max. outreach 58 ft 4 in
Pendular arm rotation (top / bottom) +70 ° / -63 °
Platform capacity 899 lb
Turret rotation 360 °
Platform rotation (right / left) 90 ° / 90 °
Number of people (indoor / outdoor) 3 / 3
Weight and dimensions
Platform weight* 29983 lb
Platform dimensions (length x width) 7 ft 7 in x 2 ft 11 in
Overall length 33 ft
Overall width 8 ft 2 in
Overall height 8 ft 9 in
Overall length (stowed) 24 ft 1 in
Overall height (stowed) 9 ft 11 in
Jib length 6 ft 7 in
Counterweight offset (turret at 90°) 4 ft 5 in
Counterweight Oversize / Reach 4 ft 5 in
Internal turning radius / External turning radius 7 ft 10 in/14 ft 5 in
Ground clearance at centre of wheelbase 1 ft 5 in
Wheelbase 9 ft 2 in
Performances
Drive speed - stowed 3 mph
Drive speed - raised 0.62 mph
Gradeability 40 %
Wheels
Tires type Solid Tires Cured-On
Standard tires 40 x 14 in / 1025 x 365 mm
Drive wheels (front / rear) 2 / 2
Steering wheels (front / rear) 2 / 2
Braking wheels (front / rear) 2 / 2
Engine/Battery
Engine brand / model Kubota - D1803-CR-TIE4B
I.C. Engine power rating / Power 49.60 Hp / 37 kW
Miscellaneous
Ground Pressure 265 PSI
Hydraulic Pressure 5802 PSI
Hydraulic oil tank capacity 25 US gal
Fuel tank 19 US gal
Vibration on hands/arms < 0.50 m/s²
Standards compliance
This machine is in compliance with:
ANSI A92.20-2018 CSA B354.6 ICES-002-Issue 6 Standard Canadian EMC
