New 2026 LINK BELT EXCAVATORS 250 X4 SCRAP LOADER | Material Handlers

Description

BASE MACHINE DESCRIPTION 250X4 SL
ENGINE – EPA Certified Final Tier 4 Isuzu AQ-4HK1X turbocharged diesel engine with electronic control (ECM) and high pressure common-rail fuel injection, 177 Net HP (132kW), 5.2 Liter displacement, 4-cylinder, water-cooled, Cooled Exhaust Gas Recirculation (CEGR), Intercooler,
Variable Geometry Turbocharger (VGT), Diesel Oxidation Catalyst (DOC) and Selective Catalytic Reduction (SCR) system with Dosing Control Module (DCM) and Heated DEF lines and tank.

Electronic fuel pump and priming, Fuel cooler, 50 amp alternator, Auto-idle, Auto-shutdown, engine Auto-warm up, Engine protection (EPF), Emergency stop, Dual stage fuel filtration, Remote oil filter, engine oil sampling port, Green plug oil drain, Double element air filters with air pre-cleaner and Reversing Fan.

HYDRAULICS – Open-center system, (2) variable displacement axial piston pumps, (1) gear pump for pilot controls, (1) axial piston pump for lifting magnet. Main control valve with one 4 spool section and one 5 spool section with auxiliary spool. Internal anti-drift valve, HBCV (Hose Burst Check Valve) for boom and arm, Double acting and rotate plumbed to arm end for grapple open/close/rotation. Oil cooler, O-ring face seals, High performance 6-micron full flow return filter, 8 micron pilot filter and Firewall, 2 pump flow for grapple open/close speed.

CONTROL SYSTEM – (3) selectable working modes (SP/H/A) and Magnet mode if equipped. Anti-theft password protection system, On-board self-diagnostic system with memory and service interval reminders. Free Swing control, Auto-idling system, One-touch decelerator, Auto-idle engine shut down, Auto engine warm up. Attachment Spool Stroke Control (SSC), Cushion attachment control, Arm-in speed control, Anti-interference device. Neutral safety start, Gate-lock safety shutoff, Disc type swing brake and swing lock, 2-speed travel and Single pedal travel, Rear view camera with pre-wired for optional cameras. RemoteCARE Telematics with no subscription fees.

OPERATOR CONTROL STATION – Pipe structured fabricated press sheet metal cab with OPG-1 top guard certified cab, (2) LED exterior work lights at cab front, Safety glass for all windows, AM/FM radio with Bluetooth® technology and USB port, Dual speakers and mute button, EM6/ISO7096 compliant air-suspension heated seat, sliding/reclining, adjustable armrests, lumber support, retractable seat belt, +/- 5 degree tilt.
Low-effort SAE controls, Control panel with illuminated soft-touch switches, High definition LCD monitor with full color 7" display, 4 position tilting consoles with memory position and rise up left console for exit, Hydraulic lock out, Auto climate control A/C and heat with air filters, defrost, Sky roof, Intermittent/continuous windshield wiper with washer, Travel alarm, Foot rests, Cup holder, Storage compartment, 12-volt accessary outlet, digital clock, 24-volt cigarette lighter, Ashtray, dome lights, coat hook, horn, (3) mirrors for cab, side and underneath, floor mat, sun visor, and OPG LEVEL I certified front guard is standard with optional OPG LEVEL II front guard.

UPPERSTRUCTURE - 18,009.8 lb. counterweight, Upper undercovers, Turntable bearing, Common key locks, LED work lights, Nonskid surface pads, ISO-Compliant Guardrails.

UNDERCARRIAGE - X Pattern carbody with 15' 3" LC long undercarriage by 8' 6" track gauge, Sealed and strutted track chain with 190mm pitch, Sealed rollers and idlers, single track guards. Two speed independent hydrostatic travel with compact planetary final drive, Disc type brakes, Adjustable track tension, Carbody belly pan, 4 lashing points (tie downs).

OPERATING WEIGHT: less tool with 800mm 3-bar grouser, 24' 3" straight boom, 19' droop-nose arm -73,193 lbs
